- Spiral mixing action
- Cool, gentle, low-oxidation kneading
- Power rotating 43.3 qt (41L) bowl
- High torque 230V industrial motor
- All-stainless food contact parts
- Wide 14.3-83 lbs (6.5-38kg) batch range
- 2-speed or variable-speed option
- Reverse function
- 60-minute timer
- Quiet operation
- Made in Italy
- Buy Now, Pay Later option through PayPal
In stock Usually ships in 3-5 business days.
Spiralmac 38kg Spiral Dough Mixer
Spiralmac spiral dough mixers are built in Italy by a family-run company that’s made quality food preparation equipment since 1964. The Spiralmac 38kg mixer is a dough expert, designed expressly to mix and knead doughs, from low to high hydration, quickly yet gently. The key feature that makes this possible is the spiral dough hook, working in combination with the dough breaker bar.
The Spiralmac’s bowl itself rotates, bringing the dough to the spinning spiral dough hook with each revolution. This action is exceptionally thorough and uniform. An integrated offset breaker bar ensures ideal metering of the dough into the spiral hook. This three-way kneading process is exceptionally thorough and fast, yet the low impact and widely distributed dough contact of the spiral hook completely avoids overworking and overheating of the dough. The 38kg mixer is available in a two-speed model and a variable speed model. The wide-range, infinitely variable speed model lets you dial in precisely the action you want. See the table below for the RPM of the bowl and spiral hook on each model.
PROFESSIONAL LINE SPIRALMAC MIXERS |
Model |
25kg |
38kg |
44kg |
|
Spiral Hook RPM |
2S |
95/190 |
95/190 |
95/190 |
VS |
100-230 |
100-230 |
100-230 |
|
Bowl RPM |
2S |
10/20 |
10/20 |
10/20 |
VS |
10-23 |
10-23 |
10-23 |
|
Volts |
2S/VS |
230 |
230 |
230 |
Watts |
2S/VS |
1800 |
2200 |
2200 |
Hertz |
2S/VS |
60 |
60 |
60 |
Phase |
2S |
3PH |
3PH |
3PH |
SV |
1PH |
1PH |
1PH |
|
Cord-End Plug |
2S |
20 Amp (NEMA L15-20P) |
20 Amp (NEMA L15-20P) |
20 Amp (NEMA L15-20P) |
SV |
20 Amp (NEMA 6-20P) |
20 Amp (NEMA 6-20P) |
20 Amp (NEMA 6-20P) |
|
2S = 2 speed / VS = Variable speed |
PROFESSIONAL DESIGN & QUALITY
Spiralmac mixers feature heavy duty chain overhead drive for the dough hook. The lower (bowl) drive is driven by a sealed, speed reduction gearbox and heavy duty chain. Sealed industrial ball bearings are used for exceptionally long life. Construction is robust throughout, with a weight of 230 lbs. Epoxy powder coating over a steel cabinet protects the handsome appearance of your Spiralmac mixer.
HIGH HYDRATION OR HEAVY DOUGHS
Thanks to the spiral hook’s action, mixtures that overtax other designs—such as pizza or bagel dough—are handled easily, quickly and efficiently in the Spiralmac 38kg mixer. Doughs of all kinds, from stiff doughs to high-hydration doughs, come out smooth, silky and perfectly developed. With its wide speed range, the Spiralmac handles the full range of dough densities. Read more about which speeds to run the mixer at based on hydration level in the "Speed Based on Hydration" paragraph below.
SUPER CAPACITY RANGE
At 60% hydration, the 38kg mixer kneads up to 83 lbs. (38kg) of dough, but also handles batches as small as 14.3 lbs (6.5kg). In terms of flour capacity that's 44 lbs (20 kg) down to 8.8 lbs (4 kg) of flour. Heavier doughs can be mixed when the hydration level is higher than 60%. To mix and knead dough below 60% hydration, like challah or bagel dough, Spiralmac recommends filling the bowl to only half capacity. Capacity of the stainless steel bowl is 43.3 qt (41L).
SPIRALMAC MIXER CAPACITIES |
Flour |
Total Dough Weight |
|
5kg |
6.6 lbs / 3 kg |
11 lbs. / 5 kg |
8kg |
11 lbs / 5 kg |
17.6 lbs. / 8 kg |
12kg |
17.5 lbs / 8 kg |
26.4 lbs. / 12 kg |
25kg |
33 lbs / 15 kg |
55 lbs. / 25 kg |
38kg |
44 lbs / 20 kg |
83 lbs. / 38 kg |
44kg |
55 lbs / 25 kg |
97 lbs. / 44 kg |
Notes
|
SPEED BASED ON HYDRATION
The Spiralmac is a variable speed mixer that has a speed dial marked from 0-10. The table below shows the maximum speed Spiralmac recommends for mixing dough at different hydration levels. These are general guidelines, as dough characteristics vary. If mixing dough that's less than 60% hydration, Spiralmac recommends only filling the bowl to 50% capacity, and mixing for only 10 minutes at a time; judgment must be exercised in any case, to avoid kneading dough so dry it’s outside of normal baking parameters, regardless of the hydration numbers. With dough over 60% hydration, dough can be mixed for up to 20-25 minutes before the mixer should be turned off for about 40 minutes.
SPEED BASED ON HYDRATION |
Hydration |
Top speed |
RPM |
55-60% |
4 |
190 |
60-70% |
5 |
210 |
70-75% |
6 |
230 |
75-80% |
7 |
250 |
80-85% |
8 |
270 |
85-90% |
9 |
290 |
Over 90% |
10 |
310 |
Permanently Lubricated Reduction Gearbox
The Spiralmac mixer is equipped with a permanently-lubricated gearbox with tempered steel helical screw. The primary drive unit is the heart of the mixer’s power transmission system, and this sealed, helical gearbox provides the ultimate in strength, efficiency and long life, maintenance-free operation.
Featuring bronze alloy bearings and a case-hardened helical screw constantly bathed in high performance synthetic oil, this speed-reduction gearbox is the gold standard of power transmission for dough mixers.
Caster Wheels
The 38kg Spiralmac mixer comes with two locking caster wheels, and two non-locking caster wheels. The wheels are easy to install upon delivery, or remove in the future, if desired.
ULTIMATE DOUGH MAKER
For commercial and home bakers, Spiralmac offers high performance and great value. The Spiralmac mixers are competitively priced, and the 38kg Spiralmac mixer is backed by an 18 month home or commercial warranty. Read the full warranty statement here.
Based on our use of this new mixer line in the PHG kitchen, we believe the exciting Spiralmac mixers will be adopted very quickly across the U.S. baking market as a premier baker’s tool.
BUY NOW, PAY LATER WITH PAYPAL |
Payment plans of 12 to 24 months, with full details available in checkout. |
Compare Spiral Dough Mixers |
Click to see our spiral dough mixer comparison table. We offer a wide selection of spiral dough mixers: |
THIS PRODUCT IS MADE IN ITALY!
